‎Chapter 5 Configuring T H E E M 1 3 X S E R I E S
82 EM13x Series SMART MULTIFUNCTION METER
 A programmable action is performed on setpoint status transition
when a setpoint event is asserted.
Generally, setpoint actions are performed independently for each
setpoint and can be repeated a number of times for the same target.
The exceptions are relay operations that are shared for each target
relay between all setpoints using an OR scheme.
A relay output is operated when one of the setpoints linked to the relay
is activated and remains operated until all of these setpoints are
released (except for latched relays that require a separate release
command to be deactivated).
Using Time Counters
Any of the general counters can be used to count the setpoint
operation time. If you select the TIME CNT n action for a setpoint, the
target counter measures the time while the setpoint is in the operated
state. The counter resolution is 0.1 hour. See
Status Display in Chapter
3 on how to examine the counters via the front display.
Configuring the Display
This setup allows configuring the meter display. It also has an entry for
launching the meter Flash Loader.
Using the Front Display
Select the Disp entry from the main menu. See Viewing and Changing
Setup Options in Chapter 3 for information on configuring parameters
via the front display.
See Table 16 for the available options.
Table 16: Display Setup Options
Display
Label
Parameter Options Default Description
AutuoScroll Display update
rate
Disabled
2 – 30sec
5 sec Defines the interval
between display updates
AutoReturn Auto return to
the main screen
Disabled,
1 – 30 mn 5 mn Enables automatic return to
the main display if no
buttons are pressed for 5
minutes
Backlight Display
Backlight period
Continuous,
1 – 10 mn
1 Defines the display
backlight light on time
duration
Phas.Power Phase powers
display mode
Enabled
Disabled
Disabled Disables or enables phase
powers in the main display
Fund.Power Fundamental
component
display mode
Enabled
Disabled
Disabled Disables or enables
fundamental values in the
main display
Local Time Settings
This setup allows you to specify your time zone, daylight saving time,
and clock synchronization options.
Disp AutoScroll
5
