‎Appendix C Setpoint Triggers and Actions

138

EM13x Series SMART MULTIFUNCTION METER

Table 25: Setpoint Actions

Designation

Description

NONE

None (no action)

OPERATE RELAY #1

Operate relay RO1

OPERATE RELAY #2

Operate relay RO2

OPERATE RELAY #3

Operate relay RO3

RELEASE RELAY #1

Release latched relay RO1

RELEASE RELAY #2

Release latched relay RO2

RELEASE RELAY #3

Release latched relay RO3

INC CNT #1

Increment counter #1

INC CNT #2

Increment counter #2

INC CNT #3

Increment counter #3

INC CNT #4

Increment counter #4

TIME CNT #1

Count operation time using counter #1

TIME CNT #2

Count operation time using counter #2

TIME CNT #3

Count operation time using counter #3

TIME CNT #4

Count operation time using counter #4

NOTIFICATION

Send a notification message

DATA LOG #1

Record data to Data Log #1
