‎Appendix D Parameters for Data Monitoring and Logging
146 EM13x Series SMART MULTIFUNCTION METER
Designation Description
TOU REG2 Billing TOU Energy Register #2 E, EH
REG2 TRF1 Tariff #1 register
REG2 TRF2 Tariff #2 register
… …
REG2 TRF8 Tariff #8 register
TOU REG3 Billing TOU Energy Register #3 E, EH
REG3 TRF1 Tariff #1 register
REG3 TRF2 Tariff #2 register
… …
REG3 TRF8 Tariff #8 register
TOU REG4 Billing TOU Energy Register #4 E, EH
REG4 TRF1 Tariff #1 register
REG4 TRF2 Tariff #2 register
… …
REG4 TRF8 Tariff #8 register
TOU MAX DMD REG1 Billing TOU Maximum Demand Register #1 E, EH
REG1 TRF1 MD Tariff #1 maximum demand
REG1 TRF2 MD Tariff #2 maximum demand
… …
REG1 TRF8 MD Tariff #8 maximum demand
TOU MAX DMD REG2 Billing TOU Maximum Demand Register #2 E, EH
REG2 TRF1 MD Tariff #1 maximum demand
REG2 TRF2 MD Tariff #2 maximum demand
… …
REG2 TRF8 MD Tariff #8 maximum demand
TOU MAX DMD REG3 Billing TOU Maximum Demand Register #3 E, EH
REG3 TRF1 MD Tariff #1 maximum demand
REG3 TRF2 MD Tariff #2 maximum demand
… …
REG3 TRF8 MD Tariff #8 maximum demand
TOU MAX DMD REG4 Billing TOU Maximum Demand Register #4 E, EH
REG4 TRF1 MD Tariff #1 maximum demand
REG4 TRF2 MD Tariff #2 maximum demand
… …
REG4 TRF8 MD Tariff #8 maximum demand
1 In 4LN3, 3LN3 and 3BLN3 wiring modes, the voltages will be line-
to neutral; for any other wiring mode, they will be line-to-line voltages.
2 The value is calculated as a relation of the maximum deviation of
phase values from a 3-phase average value to a 3-phase average.
NOTE
Designations of some enginering demands and billing energy and
demand registers are shown using a short name notation available in
PAS V1.4. By default, PAS uses long names compatible with older
versions of PAS. You can select a desired notation from the
Tools/Options/Preferences tab.
PAS does not allow to store data in files using different data names. If
you have a file uploaded with a previous version of PAS using long data
