‎Appendix E Billing/TOU Profile Log File
148 EM13x Series SMART MULTIFUNCTION METER
Appendix E Billing/TOU Profile Log
File
The following table shows the record structure for the daily billing data
profile log file.
The second column shows data abbreviations used in the PAS data log
reports. Data log file sections are highlighted in bold.
Table 27: Daily Billing/TOU Profile Data Log (Data Log #16)
Field No. Designation Description
Energy Register #1
1 REG1 Summary (total) energy reading
2 TRF1 Tariff #1 energy reading
3 TRF2 Tariff #2 energy reading
4 TRF3 Tariff #3 energy reading
5 TRF4 Tariff #4 energy reading
6 TRF5 Tariff #5 energy reading
7 TRF6 Tariff #6 energy reading
8 TRF7 Tariff #7 energy reading
9 TRF8 Tariff #8 energy reading
…
Energy Register #4
1 REG4 Summary (total) energy reading
2 TRF1 Tariff #1 energy reading
3 TRF2 Tariff #2 energy reading
4 TRF3 Tariff #3 energy reading
5 TRF4 Tariff #4 energy reading
6 TRF5 Tariff #5 energy reading
7 TRF6 Tariff #6 energy reading
8 TRF7 Tariff #7 energy reading
9 TRF8 Tariff #8 energy reading
Daily Maximum Demand Register #1
1 REG1 MD Summary (total) max. demand reading
2 TRF1 MD Tariff #1 max. demand reading
3 TRF2 MD Tariff #2 max. demand reading
4 TRF3 MD Tariff #3 max. demand reading
5 TRF4 MD Tariff #4 max. demand reading
6 TRF5 MD Tariff #5 max. demand reading
7 TRF6 MD Tariff #6 max. demand reading
8 TRF7 MD Tariff #7 max. demand reading
9 TRF8 MD Tariff #8 max. demand reading
…
Daily Maximum Demand Register #4
1 REG4 MD Summary (total) max. demand reading
2 TRF1 MD Tariff #1 max. demand reading
3 TRF2 MD Tariff #2 max. demand reading
4 TRF3 MD Tariff #3 max. demand reading
5 TRF4 MD Tariff #4 max. demand reading
6 TRF5 MD Tariff #5 max. demand reading
