‎Chapter 9 Viewing F I L E S
EM13x Series SMART MULTIFUNCTION METER 123
Delta Measurements
To measure the distance between two waveform or trend points, click
on the Delta button
, then click on the first point, and then click on
the second point.
The first reference point is still frozen until you uncheck and check the
Delta button again, while the second point can be placed anywhere
within the graph line by clicking on the graph to the left or right from
the reference point.
To disable delta measurements, click on the Delta button once again.
Using a Zoom
You can use a horizontal and, for waveforms, also a vertical, zoom to
change size of your graph.
Use the buttons on your local toolbar to zoom in and
zoom out. One click gives you a 100-percent horizontal or 50-percent
vertical zoom. Two buttons
representing magnifying glasses
give you a proportional zoom in both directions.
Copying a Graph
To copy a graph, or its part, into the Clipboard or into another
application such as Microsoft Excel or Word:
Click on the graph window with the right mouse button and choose
Copy All, or Copy Waveform. Some windows may have additional
options.
Position the cursor at the place where you whish to copy the graph.
Click the Paste button on the application's toolbar or select Paste
from the Edit menu.
Printing a Graph
To check how the graph appears on a printed page, select Print
Preview from the File menu.
To print a graph to a printer, click on the Print button
on the PAS
toolbar, select a printer and click OK.
9.3 Viewing the Event Log
The Event log contains time-tagged events related to configuration
changes, resets and device diagnostics.
The Event log is displayed in a tabular view, one event per row. Use
the scroll bar to view the entire log contents.
