‎Appendix B Analog Output Parameters
134 EM13x Series SMART MULTIFUNCTION METER
Appendix B Analog Output
Parameters
The following table lists parameters that can be provided on the
meter’s analog outputs.
Table 23: Analog Output Parameters
Designation Description
NONE None (output disabled)
1-Cycle Phase Values
V1/12 RT 1 V1/V12 Voltage
V2/23 RT 1 V2/V23 Voltage
V3/31 RT 1 V3/V31 Voltage
V12 RT V12 Voltage
V23 RT V23 Voltage
V31 RT V31 Voltage
I1 RT I1 Current
I2 RT I2 Current
I3 RT I3 Current
1-Cycle Total Values
kW RT Total kW
kvar RT Total kvar
kVA RT Total kVA
PF RT Total PF
PF LAG RT Total PF Lag
PF LEAD RT Total PF Lead
1-Cycle Auxiliary Values
In RT In Current
FREQ RT Frequency
1-Sec Phase Values
V1/12 AVR 1 V1/V12 Voltage
V2/23 AVR 1 V2/V23 Voltage
V3/31 AVR 1 V3/V31 Voltage
V12 AVR V12 Voltage
V23 AVR V23 Voltage
V31 AVR V31 Voltage
I1 AVR I1 Current
I2 AVR I2 Current
I3 AVR I3 Current
1-Sec Total Values
kW AVR Total kW
kvar AVR Total kvar
kVA AVR Total kVA
PF AVR Total PF
PF LAG AVR Total PF Lag
PF LEAD AVR Total PF Lead
1-Sec Auxiliary Values
In AVR In Current
FREQ AVR Frequency
