‎Appendix C
EM13x Series SMART MULTIFUNCTION METER 137
Designation Description
LO I3 AVR Low I3 current
1-Sec Values on any Phase
HI VOLT AVR 1 High voltage
LO VOLT AVR 1 Low voltage
HI AMPS AVR High current
LO AMPS AVR Low current
1-Sec Total Values
HI kW IMP AVR High total kW import
HI kW EXP AVR High total kW export
HI kvar IMP AVR High total kvar import
HI kvar EXP AVR High total kvar export
HI kVA AVR High total kVA
HI PF LAG AVR Low total PF Lag
HI PF LEAD AVR Low total PF Lead
1-Sec Auxiliary Values
HI In AVR High neutral current
HI FREQ RT High frequency
LO FREQ RT Low frequency
Demands
HI V1/12 DMD 1 High V1/V12 Volt demand
HI V2/23 DMD 1 High V2/V23 Volt demand
HI V3/31 DMD 1 High V3/V31 Volt demand
HI I1 DMD High I1 Ampere demand
HI I2 DMD High I2 Ampere demand
HI I3 DMD High I3 Ampere demand
HI kW IMP BD High block kW import demand
HI kvar IMP BD High block kvar import demand
HI kVA BD High block kVA demand
HI kW IMP SD High sliding window kW import demand
HI kvar IMP SD High sliding window kvar import demand
HI kVA SD High sliding window kVA demand
HI kW IMP ACD High accumulated kW import demand
HI kvar IMP ACD High accumulated kvar import demand
HI kVA ACD High accumulated kVA demand
HI kW IMP PRD High predicted kW import demand
HI kvar IMP PRD High predicted kvar import demand
HI kVA PRD High predicted kVA demand
Time and Date Parameters
DAY OF WEEK Day of week
YEAR Year
MONTH Month
DAY OF MONTH Day of month
HOURS Hours
MINUTES Minutes
SECONDS Seconds
MINUTE INTERVAL Minute interval: 1-5, 10, 15, 20, 30, 60 min
1 In 4LN3, 3LN3 and 3BLN3 wiring modes, the voltages will be line-
to-neutral; for any other wiring mode, they will be line-to-line
voltages.
