‎Chapter 5 Configuring T H E E M 1 3 X S E R I E S
68 EM13x Series SMART MULTIFUNCTION METER
Using the Front Display
Select the Basic entry from the main menu. See Viewing and Changing
Setup Options in Chapter 3 for information on configuring parameters
via the front display.
See the table below for the Basic Setup options.
Using PAS
Select General Setup from the Meter Setup menu. See the table
below for the Basic Setup options.
Table 8: Basic Setup Options
Display
Label
Parameter Options Default Description
Conf Wiring Mode See Table 9 4Ln3 The wiring connection of the device
PT Ratio PT Ratio 1.0-6500.0 1.0 The phase potential transformer’s
primary to secondary ratio
PT Factor PT Ratio Multiplier Ч1, Ч10 Ч1 PT Ratio multiplication factor. Used
in extra high voltage networks to
accommodate the PT ratio for
500 kV and higher networks.
CT CT Primary Current 1-50000 A 5 A The primary rating of the phase
current transformer
PowDmdPer Power block
demand period
1, 2, 3, 5, 10, 15,
20, 30, 60 min,
E=external sync
15 min The length of the demand period
for power demand calculations. If
the external synchronization is
selected, a pulse front on the
digital input DI1 denotes the start
of the demand interval.
Num.Per. The number of
blocks in the
sliding demand
window
1-15 1 The number of blocks to be
averaged for sliding window
demands
ADmdPer. Volt/Ampere
Demand Period
0-1800 sec 900 sec The length of the demand period
for ampere and volt demand
calculations
Freq Nominal Frequency 50,60,25,400 Hz 60 Hz The nominal line frequency
MaxDmdLd Maximum Demand
Load Current
0-50000 A 0 The maximum demand load
current (0 = CT primary current)
1. Always specify the wiring mode and transformer ratings prior to
setting up setpoints and analog outputs.
2. The maximum value for the product of the phase CT primary
current and PT ratio is 57,500,000. If the product is greater, power
readings are zeroed.
Basic Exit
LONG PRESS
Basic Conf
4Ln3
SCROLL until
CT menu
Basic CT
50
