‎Appendix C Setpoint Triggers and Actions

136

EM13x Series SMART MULTIFUNCTION METER

Appendix C Setpoint Triggers and

Actions

Table 24: Setpoint Triggers

Designation

Description

NONE

None (condition is not active)

Status Inputs

STAT INP #1 ON

Status input #1 ON

STAT INP #2 ON

Status input #2 ON

STAT INP #3 ON

Status input #3 ON

STAT INP #4 ON

Status input #4 ON

STAT INP #5 ON

Status input #5 ON

STAT INP #6 ON

Status input #6 ON

STAT INP #1 OFF

Status input #1 OFF

STAT INP #2 OFF

Status input #2 OFF

STAT INP #3 OFF

Status input #3 OFF

STAT INP #4 OFF

Status input #4 OFF

STAT INP #5 OFF

Status input #5 OFF

STAT INP #6 OFF

Status input #6 OFF

Relays

RELAY #1 ON

Relay #1 ON

RELAY #2 ON

Relay #2 ON

RELAY #3 ON

Relay #3 ON

RELAY #1 OFF

Relay #1 OFF

RELAY #2 OFF

Relay #2 OFF

RELAY #3 OFF

Relay #3 OFF

Phase Reversal

POS PHASE REVERSAL

Positive phase rotation reversal

NEG PHASE REVERSAL

Negative phase rotation reversal

Low/High 1-Cycle Values on any Phase

HI VOLT RT

1

High voltage

LO VOLT RT

1

Low voltage

HI AMPS RT

High current

LO AMPS RT

Low current

HI V THD

2

High voltage THD

HI I THD

2

High current THD

HI KF RT

High K-Factor

HI I TDD

High current TDD

1-Cycle Auxiliary Values

HI FREQ RT

High frequency

LO FREQ RT

Low frequency

HI V UNB% RT

1

High voltage unbalance

HI I UNB% RT

High current unbalance

1-Sec Phase Values

HI I1 AVR

High I1 current

HI I2 AVR

High I2 current

HI I3 AVR

High I3 current

LO I1 AVR

Low I1 current

LO I2 AVR

Low I2 current
