CHAMPION EEUCCW8 User Manual
Page 99
91
Fill Piping Assembly (no electric booster)
1
332454
BRACKET, 1/2" PIPE SUPPORT
2
2
100184
NIPPLE, 3/4" NPT X CLOSE BRASS
2
3
100209
NIPPLE, 1/2" NPT X CLOSE BRASS
3
4
102438
ELBOW, STREET, 1/2" NPT X CLOSE BRASS
1
5
102504
PLUG, 1/2" NPT SQ. HEAD, BRASS
1
6
102514
TEE, 1/2" NPT BRASS
1
7
102525
TEE, RED. 3/4" X 1/2" X 3/4" NPT BRASS
1
8
102526
TEE, RED. 3/4" X 3/4" X 1/2" NPT BRASS
1
9
102549
UNION, 1/2" NPT BRASS
1
10
102570
NIPPLE, 1/2" NPT X 4: LG. BRASS
1
11
107967
HEX GRIP NUT, 1/4-20 SST W/NYLON
2
12
108265
VALVE, PRESSURE REGULATING, 1/2" NPT BRONZE
1
13
109879
FITTING, COMP. 7/8" OD X 3/4" MPT BRASS
1
14
109925
FITTING, COMP. 5/8" OD X 1/2" MPT BRASS
1
15
110768
STRAINER, LINE 3/4" NPT BRONZE FEMALE
1
16
113352
VALVE, SOLENOID 1/2" NPT HW 115VAC
1
---
113392
KIT, REPAIR 1/2" SOLENOID VALVE
A/R
---
113357
COIL, SOLENOID 1/2" 115VAC
A/R
