39
Operation
Operation
REMOTE
START / STOP
PUSH BUTTON
STATION
Note:
The wash pumps operate on a timed cycle that will automatically stop the wash pumps when the wares
have moved through the machine, are sanitized in the final rinse, and then exit the machine.
It is important that the electric eyes be cleaned regularly to prevent soils from obstructing the infrared
beam. Clean the electric eyes with a mild detergent and a soft cloth. Do not use a scouring pad.
Electric-Eyes and Idle Pump Start
A Remote Start/Stop Station is
located on the load-end of the dishwasher.
Remote Start/Stop Stations
When the conveyor belt is moving the operator can stop the belt
without using the switches on the control cabinet.
The standard Start/Stop switch station located on the load-end of the
dishwasher. An optional station is available as an option.
To operate the Start/Stop station:
1. Push the Stop switch. The conveyor belt will stop moving.
2. The timed cycle will pause.
3. Push the Start switch and the conveyor belt will run. The
timed cycle will resume where it left off.
The wash pumps start automatically when wares that
are placed on the conveyor belt pass through a set of
electric eyes that are mounted on the load-end of the
dishwasher. The electric eyes create an infrared beam
across the belt which, when blocked by wares, start the
wash pumps (see the photo to the right).
To start the wash pumps using the electric eyes:
1. Place wares on the belt.
2. Start the conveyor belt from the control panel
or the Start/Stop station.
3. Continuing to place wares on the conveyor belt
will activate the electric eyes and keep the wash
pumps running until wares are no longer placed
on the conveyor belt.
