Quad Rinse
Unload
Load
Power Rinse
W
ash
Prewash
Long Curtain
19"
Medium Curtain
14"
Short Curtain
10"
Install the curtain with the Part No. and short flaps facing the load end of the machine
M
M
L
L
M
M
S
S
L
204949
112445
1141
11
1141
11
204949
112445
1141
11
*
*
*
* When ordering par
ts, refer to Replacement Ser
vice
Par
ts Section for correct cur
tain par
t n
os
.
Proper curtain placement is essential for the proper operation of the dishwasher. Refer to the diagram
below and make sure the curtains are installed correctly before operating the machine.
Curtain Placement Diagram
