Page 183
175
Tank Baffles
1
100734
BOLT, HEX HD. 1/4-20 X 1/2"
2 PER BRACKET
2
106482
WASHER, LOCK 1/4" SPLIT
2 PER BRACKET
3
329129
BRACKET, PW/W/R BAFFLE
2 PER BAFFLE
4
331338
BRACKET, E2 BAFFLE
2 PER BAFFLE
5
329805
BAFFLE, EUCCW, PW/W/R
2 PER SECTION
6
330691
BAFFLE, EUCC, PW/W/R
2 PER SECTION
7
331337
BAFFLE, EUCCW, E2
1 PER SECTION
8
331423
BAFFLE, EUCC, E2
1 PER SECTION
Part
No.
Item
No.
Description
Qty.
