38
Operation
Operation
Control Panel Digital Temperature Display
Digital Temperature Display Meters
Right-to-Left (R-L)
Operation Shown
The wash tanks, auxiliary rinse, and final rinse water temperatures are displayed on digital displays located
on the right-side of the control panel. The displays are labeled according to the tank or rinse water section
that is being monitored. The illustrations above and below show the arrangement for a Right-to-Left
dishwasher. The arrangement would be reversed for a Left-to-Right machine.
The minimum temperatures shown below must be maintained when the dishwasher is washing wares. A
longer wait time or corrective measures should be taken immediately to maintain the temperatures.
Final Rinse Aux. Rinse Rinse Wash Prewash
Minimum
180 °F
82 °C
Minimum
165 °F
74 °C
Minimum
160 °F
71 °C
Minimum
150 °F
66 °C
No
Minimum
Required
ATTENTION
The temperature displays must be checked repeatedly whenever the wash pumps are running and
wares are being washed to make sure that the proper temperatures are being maintained.
