Drive Shaft Assembly
452960
1
109010
HEX GRIP NUT, 3/8-16 SST W/NYLON
8
2
104618
WASHER FLAT, 3/8" SST
8
3
109958
BEARING, 4-BOLT 1" UC DRIVE
2
4
100746
BOLT, HEX HD., 3/8-16 X 1-1/4" SST
8
5
111480
BOLT, HEX HD., 3/8-16 X 3/4" SST W/LOCTITE
3
6
113970
SPROCKET, UC CONVEYOR DRIVE
3
7
107305
KEY, 1/4" X 1/4" X 1-1/2" LG. SST
3
8
330011
SHAFT, DRIVE EUCCW
1
---
206682
SHAFT, DRIVE EUCC
1
9
106679
KEY, 1/4" X 1/4" X 2-1/2" LG. SST
1
10
114484
MOTOR, GEAR 230V/3
1
---
114597
MOTOR, GEAR 480V/3
1
11
332979
BRACKET, MOTOR MOUNTING
1
12
110076
TENSION ARM ASSY
1
13
104265
BUSHING, 3/4" X 3/4" X 3/4" LG. BRONZE
1
14
106521
SPROCKET, 50B8, 5/8" BORE W/KEY
1
15
114639
SPROCKET, 50B11T, 3/16" KEY
1
16
106619
KEY, 3/16" X 3/16" X 1" LG. SST
1
17
206959
CHAIN, #50
1
18
100740
BOLT, HEX HD., 5/16-18 X 1" SST
7
19
106013
WASHER, LOCK 5/16" SPLIT SST
7
20
102376
WASHER, FLAT 5/16" SST
7
21
100154
HEX PLAIN NUT, 5/16-18 SST
7
22
101149
LINK, CONNECTING #50
1
23
100485
TORQUE LIMITER ASSY. (Includes A-D below)
1
24
101153
LINK, OFFSET #50
1
25
107183
MOTOR, 1/2 HP, DRIVE MV 3 PH
1
26
113688
SHEAVE
1
27
100792
BELT, BRIVE
1
28
100444
SHEAVE
1
29
105285
GEAR
1
30
110300
GEARBOX
1
A
104271
BUSHING
1
B
102315
DISC, FRICTION
2
C
108095
WASHER, SPRING
2
D
107700
WASHER, LOCK
1
(For S/N J09072662)
(For S/N J09072662)
(For S/N J09072662)
(For S/N J09072662)
(For S/N J09072662)
(For S/N J09072662)
