CHAMPION EEUCCW8 User Manual
Page 177
169
453110
Curtain Installation B30/C6 RL
1
100734
CAP SCREW,HEX HEAD,1/4-20 X 1/2 SST
16
2
106026
WASHER,FLAT,1/4x5/8x.06 SST
16
3
106482
WASHER,LOCK,1/4 SPLIT,SST
16
4
112445
CURTAIN,SHORT,14 X 32,NUCCW
6
5
114110
CURTAIN,SHORT,14 X 34 1/4,EUCCW
1
6
114111
CURTAIN,LONG,19 X 34 1/4,EUCCW
2
7
204949
CURTAIN,SHORT,10 X 32,NUCCW E2
1
8
205432
ROD,CURTAIN,5/16 X 32"LG.SST,UCCW
3
9
206581
ROD,CURTAIN,5/16 X 34 1/4"LG.SST,UCCW
7
10
329719-2
BAFFLE, CURTAIN HANGER.MANIFOLD MTD,LH
2
11
329720-1
BAFFLE, CURTAIN HANGER,HOOD MTD,LH
2
12
329720-2
BAFFLE, CURTAIN HANGER,HOOD MTD,RH
3
13
331200-1
BAFFLE, CURTAIN HANGER,E2 CENTER,R-L
1
