Drive Inverter Control Box
1
113769-4
DIN RAIL, 35MM X 15MM
1
2
114499
INVERTER, DRIVE, 1/2HP 200/230VAC
1
3
114512
TERMINAL, SINGLE, ST 2.5, (GRAY)
6
4
114514
TERMINAL, SINGLE, ST 2.5, (WHITE)
3
5
114516
END COVER, SINGLE TERMINAL, D-ST 2.5
1
6
114517
TERMINAL, DOUBLE, STTB 2.5
3
7
114518
END COVER, DOUBLE TERMINAL, D-STTB 2.5
1
8
114519
END BLOCK, E/NS 35 N
2
9
332653
COVER, DRIVE INVERTER BOX
1
10
332655
BODY, WELDMENT, DRIVE INVERTER BOX
1
11
332658
WRAP WELDMENT, DRIVE INVERTER BOX
1
12
332659
INNER PANEL, WELDMENT, DRIVE INVERTER BOX
1
13
114499
VFD, 1/2 HP, 200-230V/60/3 (Altivar 12)
1
----
114500
VFD, 1/2 HP, 400/460V/60/3 (Altivar 31 and 312)
1
