101
Hot Water Coil Tank Heat EEUCCW
1 100154 HEX PLAIN NUT, 5/16-18 SST 8
2 100585 LOCKNUT, 1” NPT BRASS 2
3 100740 BOLT, HEX DF. 5/16-18 X 1” SST 8
4 102376 WASHER, FLAT 5/16 SST 8
5 106013 WASHER, LOCK 5/16 SPLIT SST 8
6 108345 GASKET 2
7 331798 COIL, WELDMENT, HOT WATER C4 EEUCCW 1
--- 333939 COIL, WELDMENT, HOT WATER C3 EEUCCW 1
8 331799 PLATE, HOT WATER COIL, MOUNTING 1
9 100184 NIPPLE, 3/4” NPT X CLOSE, BRASS 6
10 102396 BUSHING, RED. 1” NPT X 3/4” NPT BRASS 1
11 102450 ELBOW STREET, 1” NPT X 90° BRASS 1
12 102551 UNION, 1” NPT, BRASS 1
13 102772 NIPPLE, 1” NPT X 6-1/2” LG. BRASS 1
14 106911 UNION, ELBOW, 3/4” NPT FEMAIL BRASS 3
15 111854 PUMP, HOT WATER RECIRCULATING, BRONZE 1
16 111860 FLANGE KIT, 1” NPT BRONZE HWC PUMP 1
(Order Separately - does not come with item 15)
17 100123 PETCOCK, 1/4” NPT FEMALE, BRASS 1
18 100848 VALVE, FLOW CONTROL, 3/4” NPT 6 GPM 1
(Prior to S/N J10092820)
19 100853 CHECK VALVE, 3/4” NPT BRONZE 1
20 102657 NIPPLE, 3/4” NPT X 5” LG. BRASS 1
21 107418 TEE, RED. 3/4” X 3/4” X 1/4” BRASS 1
22 110656 HOSE BARB, 1/4” MPT X 1/4” OD X 90° BRASS 1
23 114461 VALVE, BALL, 3/4” FNPT BRASS W/SETTING INDICATOR 1
(Beginning with S/N J10092820 and above)
