CHAMPION EEUCCW8 User Manual
Page 95
87
Electric Booster Installation
1
100003
HEX PLAIN NUT 1/4-20 SST
11
2
100097
SCREW, TRUSS HD. 10-32 X 1/2” SST
2
3
100100
SCREW, ROUND HD., 8-32 X 1/4” SST
2
4
100109
WELD STUD 1/4-20 X 1/2“ LG. SST
2
5
100113
CAP, 3/4” NPT SST
1
6
100154
HEX PLAIN NUT, 5/16-18 SST
6
7
100734
BOLT, HEX HD., 1/4-20 X 1/2” SST
2
8
100736
BOLT, HEX HD., 1/4-20 X 3/4” SST
2
9
100739
BOLT, HEX HD., 5/16-18 X 3/4” SST
2
10
100740
BOLT, HEX HD., 5/16-18 X 1” SST
4
11
102376
WASHER, FLAT 5/16-18 SST
4
12
414331
TANK, BOOSTER WELDMENT
1
13
328254
BRACKET, BOOSTER SUPPORT, W/HOLE
1
14
102505
PLUG, 3/4” NPT SQ. HD., BRASS
1
15
106013
WASHER , LOCK 5/16” SPLIT SST
6
16
106026
WASHER, FLAT 1/4” X 5/8” X .06” SST
2
17
106482
WASHER, LOCK 1/4” SPLIT SST
14
18
107967
HEX GRIP NUT, 1/4-20 SST W/NYLON
6
19
108576
BOOSTER, HEATER COVER
1
20
109069
THERMOSTAT, CONTROL WITH CAPILLARY
1
21
109682
BOX, THERMOSTAT COVER
1
22
330571
BRACKET, PIPING SUPPORT, ELECTRIC BOOSTER
1
23
109985
O-RING, BOOSTER HEATER
3
24
110561
THERMOSTAT, HI-LIMIT WITH CAPILLARY
1
25
206668
ANGLE, ELECTRIC BOOSTER SUPPORT
2
26
206669
ANGLE, ELECTRIC BOOSTER SUPPORT
1
27
314102
BOX, DUAL THERMOSTAT
1
28
601931
SEE NEXT PAGE FOR FILL PIPING BREAKDOWN
1
29
102392
BUSHING, REDUCING, 3/4" NPT X 1/2" NPT BRASS
1
30
102485
NIPPLE, 1/2" NPT X 1-1/2" NPT BRASS
1
31
102435
ELBOW, 1/2" NPT X 90° BRASS
1
32
100209
NIPPLE, 1/2" NPT X CLOSE BRASS
3
33
102549
UNION, 1/2" NPT BRASS
1
34
102514
TEE, 1/2" NPT BRASS
1
35
109925
FITTING, COMP. 5/8" OD X 1/2" MPT BRASS
2
36
113352
VALVE, SOLENOID 1/2" NPT 120VAC
1
---
113392
KIT, REPAIR 1/2" SOLENOID VALVE
A/R
---
113357
COIL, 1/2" SOLENOID VALVE 120VAC
A/R
