17
Installation
Installation
Inverter Conveyor Drive Motor Speed Control
When the conveyor belt is moving normally, the VFD Display
will indicate a number on the display that is calibrated at the
factory.
The conveyor belt speed is set at the factory to
run in the three operation modes. The modes are
selected by pressing a mode switch located on
the top-mounted control cabinet. The modes are:
Energy Saver Mode
Normal Mode
Fast Mode
ESC ENT
VFD DISPLAY
CAUTION
The Variable Frequency Drive (VFD)
is a solid-state motor control.
Changing the factory settings without
prior authorization by the factory will void the
warranty of the VFD and the Dishwasher.
Variable Frequency Drive (VFD)
for the Conveyor Drive Motor
Variable Frequency Drive (VFD)
shown with the Conveyor Drive Motor
