173 control cabinet – CHAMPION EEUCCW8 User Manual
Page 181
173
Control Cabinet
1
180081
TRANSFORMER, 750VA 240/480:120V
2
2
111827
CONTACTOR, 60FLA, 3P 120V COIL
1
3
111153
BLOCK, FUSE DIN RAIL 600V 30A
2
4
111823
FUSE, LPCC-6 600V TIME DELAY
4
5
103310
LUG, GROUND
1
6
111833
TERMINAL BLOCK, 175A, 3 POLE, 600V
1
7
108122
CONTACTOR, 12A
4
8
113161
STARTER, MOTOR 9-14.0A
3
9
702023
BLOWER DRYER TIMER KIT
1
---
111036
RELAY 120VAC
1
----
111068
SOCKET, RELAY
1
10
180081
TRANSFORMER, 750A (Located in booster control cabinet)
1
11 114413
TIMER, 30 SECONDS
1
12
180171
BLOCK, FUSE 600V/60A 3P J-TYPE
1
13
180172
FUSE, J 35A, 600V, FAST-ACTING
9
14
111277
TRANSFORMER, 120V:24V50/60HZ
1
15
100294
TERMINAL BLOCK, 6PT
1
16
304326
BRACKET, SWITCH
1
17
107198
SWITCH, TOGGLE 3PDT, ON/OFF
1
18
108370
WASHER, LOCK
1
19
104858
NAMPEPLATE, AUTOMATIC/MANUAL
1
20
114640
TIMER, UC PUMP AND RINSE
2
21
114641
BASE, TIMER
2
22
114644
RELAY, LATCH DPDT 24VAC, 8A
2
23
114645
BASE, RELAY
2
24
114642
RELAY, DPDT 24VAC, 8A
19
25
114643
BASE, RELAY
19
26
111068
RELAY, 2PDT 120VAC, 10A
3
27
111036
RELAY, SOCKET
3
28
114521
END COVER, SINGLE TERMINAL D-MZB
1
29
114520
TERMINAL, SINGLE MZB 1.5-NS35
10
30
114489
GAUGE, DIGITAL TEMPERATURE DISPLAY
3
31
114508
CABLE ASSEMBLY, 4-COND. FOR THERMISTOR
3
32
114505
BREAKER, 14A, ON-OFF
1
33
702084
LED ASSY.
3
34
114554
SWITCH, PIEZO MOMENTARY N.O. 16MM
3
35
0512213
SWITCH, PIEZO MOMENTARY N.C. 22MM
1
36
114565
DECAL 36" CONTROL CAB RL DIGITAL DISPLAY
1
---
114654
DECAL 36" CONTROL CAB LR DIGITAL DISPLAY
N/S
Temperature sensing thermistor are installed the wash tanks and final rinse piping.
The temperature signals are connected to the digital temperature display gauges (Item 30) in the main control cabinet.
A
114435
THERMISTOR, 10K 36" LEAD
1
B
0512299
ADAPTER, THERMISTOR
1
C
0501836
O-RING
1
D
201029
LOCKNUT 1/2" NPT NP
1
