CHAMPION EEUCCW8 User Manual
Page 179
171
453111
Curtain Installation B30/C6 LR
1
100734
16
2
106026
WASHER,FLAT,1/4x5/8x.06 SST
16
3
106482
WASHER,LOCK,1/4 SPLIT,SST
16
4
112445
CURTAIN,SHORT,14 X 32,NUCCW
7
5
114111
CURTAIN,LONG,19 X 34 1/4,EUCCW
2
6
204949
CURTAIN,SHORT,10 X 32,NUCCW AUX. RINSE
1
7
205432
ROD,CURTAIN,5/16 X 32"LG.SST,UCCW
3
8
206581
ROD,CURTAIN,5/16 X 34 1/4"LG.SST,UCCW
7
9
329719-1
BAFFLE, CURTAIN HANGER.MANIFOLD MTD,RH
2
10
329720-1
BAFFLE, CURTAIN HANGER,HOOD MTD,LH
3
11
329720-2
BAFFLE, CURTAIN HANGER,HOOD MTD,RH
2
12
331200-2
BAFFLE, CURTAIN HANGER, AUX. RINSE CENTER,L-R
1
HEX HEAD, 1/4-20 X 1/2 SST
