Set the value in the Transport bar’s numerical Project End display (by click-dragging or
double-clicking the value).
Project End display
Note: If your Transport bar does not include the Project End display, Control-click it and
choose Customize Transport Bar in the shortcut menu. Select the Tempo/Project End
checkbox in the Customize Transport Bar pane.
As soon as Logic Express reaches the project end point, it stops automatically, except
when recording. In this situation, the project end point is automatically moved to the
end of the recording.
Setting the Basic Project Playback Volume
You can set the basic project playback volume by dragging the Master Volume slider
found at the right of the Transport bar. This slider is directly tied to the Master channel
strip in the Mixer, and acts as a master volume control for all audio and software instrument
tracks.
Important: This slider not only sets the playback volume of your project, but also affects
the overall volume of your mix.
Click the Reset Master Volume button to the right of the Master Volume slider to set the
slider to 0 dB.
175 Chapter 7 Working with Projects
