Displaying BGP4 information
Displaying the BGP4 route table
BGP4 uses filters you define as well as the algorithm described in “How BGP4 selects a path for a
route” on page 283 to determine the preferred route to a destination. BGP4 sends only the
preferred route to the router IP table. However, if you want to view all the routes BGP4 knows about,
you can display the BGP4 table using either of the following methods.
To view the BGP4 route table, enter the following command.
Syntax: show ip bgp routes [[network] ip-addr] | num| [age secs] | [as-path-access-list num] |
[best] | [cidr-only] | [community num | no-export | no-advertise | internet | local-as] |
[community-access-list num] | [community-list num | [detail option] | [filter-list num,
num,...] | [next-hop ip-addr] | [no-best] | [not-installed-best] | [prefix-list string] |
[regular-expression regular-expression] | [route-map map-name] | [summary] |
[unreachable]
The ip-addr option displays routes for a specific network. The network keyword is optional. You can
enter the network address without entering “network” in front of it.
The num option specifies the table entry with which you want the display to start. For example, if
you want to list entries beginning with table entry 100, specify 100.
The age secs parameter displays only the routes that have been received or updated more recently
than the number of seconds you specify.
The as-path-access-list num parameter filters the display using the specified AS-path ACL.
The best parameter displays the routes received from the neighbor that the Layer 3 switch selected
as the best routes to their destinations.
The cidr-only option lists only the routes whose network masks do not match their class network
length.
IBGP routes selected as best routes The number of “best” routes in the BGP4 route table that are IBGP routes.
EBGP routes selected as best routes The number of “best” routes in the BGP4 route table that are EBGP routes.
TABLE 68 BGP4 summary route information (Continued)
Field Description
Brocade#show ip bgp routes
Total number of BGP Routes: 97371
Status A:AGGREGATE B:BEST b:NOT-INSTALLED-BEST C:CONFED_EBGP D:DAMPED
E:EBGP H:HISTORY I:IBGP L:LOCAL M:MULTIPATH S:SUPPRESSED
Prefix Next Hop Metric LocPrf Weight Status
1 10.0.0.0/8 192.168.4.106 100 0 BE
AS_PATH: 65001 4355 701 80
2 10.4.0.0/8 192.168.4.106 100 0 BE
AS_PATH: 65001 4355 1
3 10.60.212.0/22 192.168.4.106 100 0 BE
AS_PATH: 65001 4355 701 1 189
4 10.6.0.0/8 192.168.4.106 100 0 BE
AS_PATH: 65001 4355 3356 7170 1455
5 10.8.1.0/24 192.168.4.106 0 100 0 BE
AS_PATH: 65001
