148 Brocade ICX 6650 Layer 3 Routing Configuration Guide
53-1002603-01
RIP parameter configuration
NOTE
This example assumes that the highest RIP redistribution filter ID configured on the device is 64.
Changing the redistribution metric
When the Layer 3 Switch redistributes a route into RIP, the software assigns a RIP metric (cost) to
the route. By default, the software assigns a metric of 1 to each route that is redistributed into RIP.
You can increase the metric that the Layer 3 Switch assigns up to 15.
To change the RIP metric the Layer 3 Switch assigns to redistributed routes, enter a command such
as the following.
Brocade(config-rip-router)#default-metric 10
This command assigns a RIP metric of 10 to each route that is redistributed into RIP.
Syntax: [no] default-metric metric-value
The metri-value can be from 1 to 15.
Enabling redistribution
After you configure redistribution parameters, you need to enable redistribution.
To enable RIP redistribution, enter the redistribution command.
Brocade(config-rip-router)#redistribution
Syntax: [no] redistribution
The no form of this command disables RIP redistribution.
Removing a RIP redistribution deny filter
To remove a previously configured RIP redistribution deny filter, perform the following task:
1. Remove the RIP redistribution deny filter.
2. Disable the redistribution function.
3. Re-enable redistribution.
The following shows an example of how to remove a RIP redistribution deny filter.
Route learning and advertising parameters
By default, a Brocade Layer 3 Switch learns routes from all its RIP neighbors and advertises RIP
routes to those neighbors.
You can configure the following learning and advertising parameters:
Brocade(config-rip-router)#no deny redistribute 2 all address 192.168.0.0
255.255.0.0
Brocade(config-rip-router)#no redistribution
Brocade(config-rip-router)#redistribution
