Brocade ICX 6650 Layer 3 Routing Configuration Guide
129
53-1002603-01
Displaying IP configuration information and statistics
Displaying ARP entries
To display the entries the Layer 2 Switch has placed in its ARP cache, enter the show arp command
from any level of the CLI.
Syntax: show arp
This display shows the following information.
Displaying IP traffic statistics
To display IP traffic statistics on a Layer 2 Switch, enter the show ip traffic command at any CLI
level.
TABLE 24
CLI display of ARP cache
Field
Description
Total ARP Entries The number of entries in the ARP cache.
Maximum
capacity
The total number of ARP entries supported on the device.
IP
The IP address of the device.
Mac
The MAC address of the device.
NOTE: If the MAC address is all zeros, the entry is for the default gateway, but the Layer 2
Switch does not have a link to the gateway.
Port
The port on which the entry was learned.
Age
The number of minutes the entry has remained unused. If this value reaches the ARP aging
period, the entry is removed from the cache.
VlanId
The VLAN the port that learned the entry is in.
NOTE: If the MAC address is all zeros, this field shows a random VLAN ID, since the Layer 2
Switch does not yet know which port the device for this entry is attached to.
Brocade# show arp
Total Arp Entries : 1, maximum capacity: 1000
No.
1
IP Mac
Port Age VlanId
192.168.1.170
0000.0011.d042 7 0 1
