Brocade ICX 6650 Layer 3 Routing Configuration Guide
279
53-1002603-01
Displaying OSPF V3 Information
Displaying IPsec for a virtual link
To display IPsec for a virtual link, run the show ipv6 ospf virtual-link brief or show ipv6 ospf
virtual-link command, as the following examples illustrate.
TABLE 60
Area configuration of IPsec
Field
Description
Authentication
This field shows whether or not authentication is configured. If this field says
“Not Configured,” the IPsec-related fields (bold in example screen output) are
not displayed at all.
KeyRolloverTime
The number of seconds between each initiation of a key rollover. This field
shows the configured and current times.
KeyRolloverState
Can be:
Not active: key rollover is not active>
Active phase 1: rollover is in its first interval.
Active phase 2: rollover is in its second interval.
Current
Shows current SPI, authentication algorithm (currently ESP only), encryption
algorithm (currently SHA1 only), and the current key.
New (Inbound or
Outbound)
Shows new SPI (if changed), authentication algorithm (currently ESP only),
encryption algorithm (currently SHA1 only), and the new key.
Old (Inbound or
Outbound)
Shows old SPI (if changed), authentication algorithm (currently ESP only),
encryption algorithm (currently SHA1 only), and the old key.
OSPF messages
dropped
Shows the number of packets dropped because the packets failed
authentication (for any reason).
Brocade#show ipv6 ospf virtual-link brief
Index Transit Area ID Router ID Interface Address State
1 1 10.14.14.14 2001:db8:1:1::1 P2P
Brocade#show ipv6 ospf virtual-link
Transit Area ID Router ID Interface Address State
1 10.14.14.14 2001:db8:1:1::1 P2P
Timer intervals(sec) :
Hello 10, Hello Jitter 10, Dead 40, Retransmit 5, TransmitDelay 1
DelayedLSAck: 5 times
Authentication: Configured
KeyRolloverTime(sec): Configured: 10 Current: 0
KeyRolloverState: NotActive
Outbound: SPI:100004, ESP, SHA1
Key:1234567890123456789012345678901234567890
Inbound: SPI:100004, ESP, SHA1
Key:1234567890123456789012345678901234567890
Statistics:
Type tx rx tx-byte rx-byte
Unknown 0 0 0 0
Hello 65 65 2600 2596
DbDesc 4 4 2752 2992
LSReq 1 1 232 64
LSUpdate 11 5 1040 1112
LSAck 5 8 560 448
OSPF messages dropped,no authentication: 0
Neighbor: State: Full Address: 2001:db8:44:44::4 Interface: eth 1/1/2
