Brocade ICX 6650 Layer 3 Routing Configuration Guide 133
53-1002603-01
Chapter
2
Base Layer 3 and Routing Protocols
Table 26 lists the base Layer 3 features Brocade ICX 6650 devices support. These features are
supported in full Layer 3 software images, except where explicitly noted.
Adding a static IP route
To add a static IP route, enter a command such as the following at the global CONFIG level of the
CLI.
Brocade(config)#ip route 192.168.10.0 255.255.255.0 192.168.2.1
This command adds a static IP route to the 192.168.10.x/24 subnet.
Syntax: [no] ip route dest-ip-addr dest-mask next-hop-ip-addr [metric] [tag num]
or
Syntax: [no] ip route dest-ip-addr/mask-bits next-hop-ip-addr [metric] [tag num]
The dest-ip-addr variable is the route destination. The dest-mask variable is the network mask for
the route destination IP address. Alternatively, you can specify the network mask information by
entering a forward slash followed by the number of bits in the network mask. For example, you can
enter 192.168.0.0 255.255.255.0 as 192.168.0.0/.24. To configure a default route, enter 0.0.0.0
for dest-ip-addr and 0.0.0.0 for dest-mask (or 0 for the mask-bits variable if you specify the address
in CIDR format). Specify the IP address of the default gateway using the next-hop-ip-addr variable.
TABLE 26 Supported base Layer 3 features
Feature Brocade ICX 6650
Static IP routing Yes
Layer 3 system parameter limits Yes
Static ARP entries Yes
RIP V1 and V2
(Static RIP support only in the base Layer
3 image. The Brocade device with base
Layer 3 does not learn RIP routes from
other Layer 3 devices. However, the
device does advertise directly connected
routes.) Yes
Redistribution of IP static routes into RIP Yes
RIP default route learning Yes
Route loop prevention:
•
Split horizon
•
Poison reverse
Yes
Route-only support (supported with full
Layer 3 image only) Yes
