Displaying BGP4 information
lists the field definitions for the command output.
TABLE 64
BGP4 summary information
Field
Description
Router ID
The Layer 3 switch router ID.
Local AS Number
The BGP4 AS number the router is in.
Confederation Identifier
The AS number of the confederation the Layer 3 switch is in.
Confederation Peers
The numbers of the local autonomous systems contained in the confederation.
This list matches the confederation peer list you configure on the Layer 3 switch.
Maximum Number of Paths
Supported for Load Sharing
The maximum number of route paths across which the device can balance traffic
to the same destination. The feature is enabled by default but the default number
of paths is 1. You can increase the number from 2 through 4 paths. Refer to
“Changing the maximum number of paths for BGP4 load sharing”
Number of Neighbors
Configured
The number of BGP4 neighbors configured on this Layer 3 switch.
Number of Routes Installed
The number of BGP4 routes in the router BGP4 route table.
To display the BGP4 route table, refer to
“Displaying the BGP4 route table”
Number of Routes Advertising
to All Neighbors
The total of the RtSent and RtToSend columns for all neighbors.
Number of Attribute Entries
Installed
The number of BGP4 route-attribute entries in the router route-attributes table. To
display the route-attribute table, refer to
“Displaying BGP4 route-attribute entries”
Neighbor Address
The IP addresses of this router BGP4 neighbors.
AS#
The AS number.
Brocade#show ip bgp summary
BGP4 Summary
Router ID: 10.0.0.1 Local AS Number : 4
Confederation Identifier : not configured
Confederation Peers: 4 5
Maximum Number of Paths Supported for Load Sharing : 1
Number of Neighbors Configured : 11
Number of Routes Installed : 2
Number of Routes Advertising to All Neighbors : 8
Number of Attribute Entries Installed : 6
Neighbor Address AS# State Time Rt:Accepted Filtered Sent ToSend
10.2.3.4 200 ADMDN 0h44m56s 0 0 0 2
10.0.0.2 5 ADMDN 0h44m56s 0 0 0 0
10.1.0.2 5 ESTAB 0h44m56s 1 11 0 0
10.2.0.2 5 ESTAB 0h44m55s 1 0 0 0
10.3.0.2 5 ADMDN 0h25m28s 0 0 0 0
10.4.0.2 5 ADMDN 0h25m31s 0 0 0 0
10.5.0.2 5 CONN 0h 0m 8s 0 0 0 0
10.7.0.2 5 ADMDN 0h44m56s 0 0 0 0
10.10.0.1 4 ADMDN 0h44m56s 0 0 0 2
10.10.0.1 4 ADMDN 0h44m56s 0 0 0 2
10.150.150.150 0 ADMDN 0h44m56s 0 0 0 2
