Brocade ICX 6650 Layer 3 Routing Configuration Guide
221
53-1002603-01
Displaying OSPF information
Displaying the routes that have been redistributed into OSPF
You can display the routes that have been redistributed into OSPF. To display the redistributed
routes, enter the show ip ospf redistribute route command at any level of the CLI.
In this example, four routes have been redistributed. Three of the routes were redistributed from
static IP routes and one route was redistributed from a directly connected IP route.
Mask
The network mask for the route.
Path_Cost
The cost of this route path. (A route can have multiple paths. Each path represents a
different exit port for the Layer 3 Switch.)
Type2_Cost
The type 2 cost of this path.
Path_Type
The type of path, which can be one of the following:
•
Inter – The path to the destination passes into another area.
•
Intra – The path to the destination is entirely within the local area.
•
External1 – The path to the destination is a type 1 external route.
•
External2 – The path to the destination is a type 2 external route.
Adv_Router
The OSPF router that advertised the route to this Brocade Layer 3 Switch.
Link-State
The link state from which the route was calculated.
Dest_Type
The destination type, which can be one of the following:
•
ABR – Area Border Router
•
ASBR – Autonomous System Boundary Router
•
Network – the network
State
The route state, which can be one of the following:
•
Changed
•
Invalid
•
Valid
This information is used by Brocade technical support.
Tag
The external route tag.
Flags
State information for the route entry. This information is used by Brocade technical support.
Paths
The number of paths to the destination.
Out_Port
The router port through which the Layer 3 Switch reaches the next hop for this route path.
Next_Hop
The IP address of the next-hop router for this path.
Type
The route type, which can be one of the following:
•
OSPF
•
Static Replaced by OSPF
Arp_Index
The index position in the ARP table of the ARP entry for this path's IP address.
State
State information for the path. This information is used by Brocade technical support.
TABLE 39
CLI Display of OSPF route information (Continued)
Field
Definition
Brocade#show ip ospf redistribute route
10.3.0.0 255.255.0.0 static
10.1.0.0 255.255.0.0 static
10.11.61.0 255.255.255.0 connected
10.4.0.0 255.255.0.0 static
