xii
Brocade ICX 6650 slot and port numbering
•
Slot 2 is located on the back of the Brocade ICX 6650 device and contains ports 1 through 3
on the top row and port 4 on the bottom row. These ports are 2x40 GbE QSFP+. Refer to the
following figure.
•
Slot 3 is located on the back of the Brocade ICX 6650 device and contains ports 1 through 8.
These ports are 4 x 10 GbE breakout ports and require the use of a breakout cable. Refer to
the previous figure.
How this document is organized
This document is organized to help you find the information that you want as quickly and easily as
possible.
The document contains the following components:
•
•
“Base Layer 3 and Routing Protocols”
•
•
•
•
•
•
•
Slot 2
Slot 2 Slot 3
