114
Brocade ICX 6650 Layer 3 Routing Configuration Guide
53-1002603-01
Displaying IP configuration information and statistics
Syntax: show ip
NOTE
This command has additional options, which are explained in other sections in this guide, including
the sections following this one.
This display shows the following information.
TABLE 16
CLI display of global IP configuration information – Layer 3 Switch
Field
Description
Global settings
ttl
The Time-To-Live (TTL) for IP packets. The TTL specifies the maximum number of router hops
a packet can travel before reaching the Brocade router. If the packet TTL value is higher than
the value specified in this field, the Brocade router drops the packet.
To change the maximum TTL, refer to
arp-age
The ARP aging period. This parameter specifies how many minutes an inactive ARP entry
remains in the ARP cache before the router ages out the entry.
To change the ARP aging period, refer to
“Changing the ARP aging period”
bootp-relay-max-ho
ps
The maximum number of hops away a BootP server can be located from the Brocade router
and still be used by the router clients for network booting.
To change this value, refer to
“Changing the maximum number of hops to a BootP relay
router-id
The 32-bit number that uniquely identifies the Brocade router.
By default, the router ID is the numerically lowest IP interface configured on the router. To
change the router ID, refer to
enabled
The IP-related protocols that are enabled on the router.
disabled
The IP-related protocols that are disabled on the router.
Static routes
Index
The row number of this entry in the IP route table.
IP Address
The IP address of the route destination.
Subnet Mask
The network mask for the IP address.
Next Hop Router
The IP address of the router interface to which the Brocade router sends packets for the
route.
Metric
The cost of the route. Usually, the metric represents the number of hops to the destination.
Brocade# show ip
Global Settings
ttl: 64, arp-age: 10, bootp-relay-max-hops: 4
router-id :10.95.11.128
enabled : UDP-Broadcast-Forwarding IRDP Proxy-ARP RARP OSPF
disabled: BGP4 Load-Sharing RIP DVMRP FSRP VRRP
Static Routes
Index IP Address Subnet Mask Next Hop Router Metric Distance
1 0.0.0.0 0.0.0.0 10.157.23.2 1 1
Policies
Index Action Source Destination Protocol Port Operator
1 deny 10.157.22.34 10.157.22.26 tcp http =
64 permit any any
