- 22 -

On making all changes in the parameter settings, exit to main menu by
pressing the ESC key for a few times, until the software displays a message
box with below two option:

ENTER – save changes and exit

ESC

– abandon changes and exit

7.2.

Menu operation using external computer keyboard

All keys present on moisture analyzer’s overlay have their equivalents on a
computer keyboard PS type, described in below table:

- function keys

Description

Overlay

Start / End drying process in an active drying mode.

Entering main menu.

Entering selection menu and settings of the drying mode.

Changing the type of displayed data on drying process.

Sending current display status to a connected peripheral
device (PRINT).

Zeroing/Tarring moisture analyzer’s indication.


- navigating arrows

Moving the cursor up

Exiting one level back in menu structure

Entering the settings of a selected parameter

Moving the cursor down


- keys: ENTER / PRINT and ESC

Accepting entered value (of a parameter)

Abandoning and exiting a function / parameter without
changes
