199
Technical data:
WPY
3/6/KTP/C1/K
WPY
6/15/KTP/C1/K
WPY
15/30/KTP/C1/K
WPY
3/6/KTP/C1/R
WPY
6/15/KTP/C1/R
WPY
15/30/KTP/C1/R
Maximum capacity 3 / 6kg 6 / 15kg 15 / 30kg
Minimum capacity 20 / 40g 40 / 100g 100 / 200g
Reading division [d] 1 / 2g 2 / 5g 5 / 10g
Verification interval [e] 1 / 2g 2 / 5g 5 / 10g
Tare range -6kg -15kg -30kg
Repeatability 1 / 2g 2 / 5g 5 / 10g
Linearity ± 1 / 2g ± 2 / 5g ± 5 / 10g
Stabilization time 2s
OIML Class III
Pan size 290 × 360mm
Operation temperature -10°C to +40°C
Storage temperature -25°C to +70°C
Atmospheric humidity 10÷85% RH no condensation
Ingress protection rating IP 54
Power supply 110÷230VAC 50/60Hz – 10,5÷15VDC
Display 5,7’’ touch screen
Interfaces 2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
Net / Gross weight 6,5 / 7,8kg
Package dimensions 550 x 420 x 220mm
Technical data:
WPY 15/30/KTP/C2/K WPY 30/60/KTP/C2/K
WPY 15/30/KTP/C2/R WPY 30/60/KTP/C2/R
Maximum capacity 15 / 30kg 30 / 60kg
Minimum capacity 100 / 200g 200 / 400g
Reading division [d] 5 / 10g 10 / 20g
Verification interval [e] 5 / 10g 10 / 20g
Tare range -30kg -60kg
Repeatability 5 / 10g 10 / 20g
Linearity ± 5 / 10g ± 10 / 20g
Stabilization time 2s
OIML Class III
Pan size 290 × 360mm
Operation temperature -10°C to +40°C
Storage temperature -25°C to +70°C
Atmospheric humidity 10÷85% RH no condensation
Ingress protection rating IP 54
Power supply 110÷230VAC 50/60Hz – 10,5÷15VDC
Display 5,7’’ touch screen
Interfaces 2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
Net / Gross weight 6,5 / 7,8kg
Package dimensions 550 x 420 x 220mm
