Platform 2:
Icon Step Value Description
1. [TI] Delay [5s] Place empty
container
Pending for loading an empty container for
the third product (the first product on the 2
weighing platform)
2. [CI] Input
condition
Input 9 – „/”
Input 9 has to take increasing tendency –
press function key confirming loading a
container
3. [T] Tare Tare
Tarring the weighing platform no. 2
4. [DH] Dose
manually
0,2 kg
[Seasoning]
Manual weighing product “Seasoning”
to obtain 0,2 kg mass
5. [TI] Delay [5s] Unload
container with
product
Pending for unloading the container with
weighed product from the weighing platform
6. [CI] Input
condition
Input 12 – „/” Input 12 has to take increasing tendency –
press function key confirming unloading a
container from the weighing platform
7. [Z] Zero Zero Zeroing the weighing platform no. 2
8. [CF] Flags
condition
Signal flag 1 – „1” Checking condition, whether signal flag 1
is set to value “1” – i.e. checking whether
desired part of the process has been already
realized on the weighing platform no. 1. If
Yes, then dosing process on the second
weighing platform shall continue.
9. [O] Outputs Output 1 – „0”,
Output 12 – „1”
Output 1 is set to low status – the signal for
completing dosing process on the weighing
platfofrm no. 1 is switched off; output 12
takes the high status – the main water valve
is opened, for manual dosing of water
ingredient.
10. [DH] Dose
manually
2 kg [Water]
Manual weighing product “Water” to obtain
2kg mass
11. [O]
Outputs
Output 12 – „0”
Output 12 is set to low status – the main
water valve is closed
12. [TI] Delay [5s] Unload
container with
product
Pending for unloading the container with
weighed product from the weighing platform
13. [CI] Input
condition
Input 12 – „/” Input 12 can take increasing tendency –
press function key confirming unloading a
container from the weighing platform
14. [O]
Outputs
Output 9 – „1” Output 9 is set to high status („1”) – signal
confirming carrying out the dosing process
on the weighing platform no. 2 is lit up
15. [TI] Delay
[5s] Dosing
process completed
Displaying a text message on the terminal
confirming completion of dosing process.
