RADWAG WLY Scales - Manual (Page 196)

196
37.2. Scales of WPY series
Technical data: WPY/2 0,6/D2 WPY/2 1,5/D2 WPY/2 3/D2 WPY/2 6/D2
Maximum capacity 0,6kg 1,5kg 3kg 6kg
Minimum capacity 4g 10g 20g 40g
Reading division [d] 0,2g 0,5g 1g 2g
Verification interval [e] 0,2g 0,5g 1g 2g
Tare range -0,6kg -1,5kg -3kg -6kg
Repeatability 0,2g 0,5g 1g 2g
Linearity ± 0,2g ± 0,5g ± 1g ± 2g
Stabilization time 2s
OIML Class III
Pan size 195 x 195mm
Operation temperature -10°C to +40°C
Storage temperature -25°C to +70°C
Atmospheric humidity 10÷85% RH no condensation
Ingress protection rating IP 54
Power supply 110÷230VAC 50/60Hz – 10,5÷15VDC
Display 5,7’’ touch screen
Interfaces 2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
Net / Gross weight 2,7 / 3,6kg
Package dimensions 490 x 300 x 150mm
Technical data:
WPY
6/C1/R
WPY
15/C1/R
WPY
30/C1/R
WPY
30/C2/R
WPY
60/C2/R
WPY
6/C1/K
WPY
15/C1/K
WPY
30/C1/K
WPY
30/C2/K
WPY
60/C2/K
Maximum capacity 6kg 15kg 30kg 30kg 60kg
Minimum capacity 40g 100g 200g 200g 400g
Reading division [d] 2g 5g 10g 10g 20g
Verification interval [e] 2g 5g 10g 10g 20g
Tare range -6kg -15kg -30kg -30kg -60kg
Repeatability 2g 5g 10g 10g 20g
Linearity ± 2g ± 5g ± 10g ± 10g ± 20g
Pan size 290 X 360mm 400 × 500mm
Stabilization time 2s
OIML Class III
Operation temperature -10°C to +40°C
Storage temperature -25°C to +70°C
Atmospheric humidity 10÷85% RH no condensation
Ingress protection rating IP 54
Power supply 110÷230VAC 50/60Hz – 10,5÷15VDC
Display 5,7’’ touch screen
Interfaces 2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
Net / Gross weight 6,5 / 7,8kg 12,5 / 15kg
Package dimensions 550 x 420 x 220mm 720 x 580 x 220mm
