37. TECHNICAL PARAMETERS
37.1. Scales of WLY series
Technical data:
WLY/2
1/D2
WLY/2
2/D2
WLY/2
6/D2
WLY/2
10/D2
WLY/2
20/D2
- - - -
Maximum capacity 1kg 2kg 6kg 10kg 20kg
Minimum capacity - - 5g - -
Reading division [d] 0,01g 0,01g 0,1g 0,1g 0,1g
Verification interval [e] - - 1g - -
Tare range -1kg -2kg -6kg -10kg -20kg
Repeatability 0,03g 0,03g 0,3g 0,3g 0,3g
Linearity ± 0,03g ± 0,03g ± 0,3g ± 0,3g ± 0,3g
OIML Class - II -
Stabilization time 3s
Pan size 195 x 195mm
Operation temperature +15°C to +30°C
Storage temperature -25°C to +70°C
Atmospheric humidity 10÷85% RH no condensation
Ingress protection rating IP 54
Power supply 110÷230VAC 50/60Hz – 10,5÷15VDC
Display 5,7’’ touch screen
Interfaces 2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
Net / Gross weight 2,7 / 3,6kg
Package dimensions 490 x 300 x 150mm
Technical data:
WLY
6/C1/R
WLY
12/C1/R
WLY
30/C1/R
WLY
60/C2/R
WLY
120/C2/R
WLY
6/C1/K
WLY
12/C1/K
WLY
30/C1/K
WLY
60/C2/K
WLY
120/C2/K
- - -
Maximum capacity 6kg 12kg 30kg 60kg 120kg
Minimum capacity 5g - - 50g -
Reading division [d] 0,1g 0,2g 0,5g 1g 2g
Verification interval [e] 1g - - 10g -
Tare range -6kg -12kg -30kg -60kg -120kg
Repeatability 0,3g 0,6g 1,5g 1g 2g
Linearity ± 0,3g ± 0,6g ± 1,5g ± 1g ± 2g
OIML Class II - II -
Pan size 360 x 290mm 400 x 500mm
Stabilization time 3s
Operation temperature +15°C to +30°C
Storage temperature -25°C to +70°C
Atmospheric humidity 10÷85% RH no condensation
Ingress protection rating IP 54
Power supply 110÷230VAC 50/60Hz – 10,5÷15VDC
Display 5,7’’ touch screen
Interfaces 2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
Net / Gross weight 6,5 / 7,8kg 12,5 / 15kg
Package dimensions 550 x 420 x 220mm 720 x 580 x 220mm
