RADWAG WLY Scales - Manual (Page 198)

198
Technical data:
WLY
6/12/KTP/C1/R
WLY
12/30/KTP/C1/R
WLY
60/KTP/C2/R
WLY
60/120/KTP/C2/R
WLY
6/12/KTP/C1/K
WLY
12/30/KTP/C1/K
WLY
60/KTP/C2/K
WLY
60/120/KTP/C2/K
Maximum capacity 6 / 12kg 12 / 30kg 60kg 60 / 120kg
Minimum capacity 50g 100g 0,5kg 0,5kg
Reading division [d] 1 / 2g 2 / 5g 10g 10 / 20g
Verification interval [e] 1 / 2g 2 / 5g 10g 10 / 20g
Tare range -12kg -30kg -60kg -120kg
Repeatability 1 / 2g 2 / 5g 10g 10 / 20g
Linearity ± 1 / 2g ± 2 / 5g ± 10g ± 10 / 20g
Stabilization time 3s
OIML Class II
Pan size 360 x 290mm 400 x 500mm
Operation temperature +15°C to +30°C
Storage temperature -25°C to +70°C
Atmospheric humidity 10÷85% RH no condensation
Ingress protection rating IP 54
Power supply 110÷230VAC 50/60Hz – 10,5÷15VDC
Display 5,7’’ touch screen
Interfaces 2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
Net / Gross weight 6,5 / 7,8kg 12,5 / 15kg
Package dimensions 550 x 420 x 220mm 720 x 580 x 220mm
37.4. Scales of WPY/KTP series
Technical data:
WPY/2
0,6/1,5/KTP/D2
WPY/2
1,5/3/KTP/D2
WPY/2
3/6/KTP/D2
Maximum capacity 0,6 / 1,5kg 1,5 / 3kg 3 / 6kg
Minimum capacity 4 / 10g 10 / 20g 40 / 40g
Reading division [d] 0,2 / 0,5g 0,5 / 1g 1 / 2g
Verification interval [e] 0,2 / 0,5g 0,5 / 1g 1 / 2g
Tare range -1,5kg -3kg -6kg
Repeatability 0,2 / 0,5g 0,5 / 1g 1 / 2g
Linearity ± 1 / 2g ± 1 / 2g ± 1 / 2g
Stabilization time 2s
OIML Class III
Pan size 195 × 195mm
Operation temperature -10°C to +40°C
Storage temperature -25°C to +70°C
Atmospheric humidity 10÷85% RH no condensation
Ingress protection rating IP 54
Power supply 110÷230VAC 50/60Hz – 10,5÷15VDC
Display 5,7’’ touch screen
Interfaces 2 x USB, 2 x RS232, Ethernet, 4 Inputs / 4 Outputs
Net / Gross weight 2,7 / 3,6kg
Package dimensions 490 x 300 x 150mm
