B. Supplementary information
B−29
Festo GDCP−SFC−LACI−IO−EN en 0812NH
HMI scaling
CI 20D0h 01h, 02h Array uint8 r
Description Units of measurement and decimal places on the control panel. See CI object
20FFh.
Measuring unit
(unit of
01h
(unit of
measurement) Definition of unit of measurement.
The setting for the system of measurement only affects the display.
Note: The SFC−LACI operates internally with metric units; the CI interface with
increments.
Value: Fixed = 1: millimetres, e.Ăg. mm, mm/s, mm/s
2
Scaling size
(no of places
02h
(no. of places
after dec. point) Number of places after the decimal point. Fixed = 2.
