5.5.1 Description of the I/Os
You will find the pin allocation for the controller interface in
section 3.6.
Positioning record: I1 ... I5 In the SFC−LACI’s I/O variant, you can choose between 31
positioning records (1...31). Positioning record 0 carries out
the homing run. The positioning records are selected via the
binary code of the inputs I1 ... I5.
Positioning
record I5 (2 4 ) I4 (2 3 ) I3 (2 2 ) I2 (2 1 ) I1 (2 0 )
0 1) 0 0 0 0 0
1 0 0 0 0 1
2 0 0 0 1 0
3 0 0 0 1 1
4 0 0 1 0 0
5 0 0 1 0 1
6 0 0 1 1 0
7 0 0 1 1 1
8 0 1 0 0 0
9 0 1 0 0 1
10 0 1 0 1 0
11 0 1 0 1 1
12 0 1 1 0 0
13 0 1 1 0 1
14 0 1 1 1 0
15 0 1 1 1 1
1) Homing
