B. Supplementary information
B−22
Festo GDCP−SFC−LACI−IO−EN en 0812NH
Standstill timeout
CI 2041h 00h Var uint16 rw
Description Standstill monitoring time in [ms}: Time during which the drive must be outside
the standstill position window before the standstill monitoring responds.
Value range: 0...65535 (0xFFFF). Default: 80
Position sampling
CI 204Ah 01h...06h Struct r(w)
Description Settings for on−the−fly measurement.
For functional description:
see section 5.5.7.
Trigger mode 01h uint16 rw
Status 02h uint8 rw
Status mask 03h uint8 rw
Control 04h uint8 rw
Position
Rising edge
05h int32 r
Rising edge
Position
Falling edge
06h int32 r
Falling edge
