Chapter 2: Installation June 30, 2006
2-4 SG1-UM-8500-03
Connecting to an Ethernet Port
C
ONNECTING THE
C
RAFT
P
ORT
I
NTERFACE
In situations where a Rear I/O card is installed, the default craft port is on the Rear I/O card. Moving a jumper on the
Rear I/O card is required if you wish to use the front craft port.
P OWERING U P THE SG-1
Connect to facility power using an AC power cord and confirm proper function of the AC power supplies.
I NSTALLING C ARDS AND B LANK F ACEPLATES
Install SG-1 cards in the appropriate slots in the SG-1 chassis as indicated below. When slots do not have cards
installed, use blank faceplates as indicated below.
Installing Cards
Once you’ve powered up the chassis, as described in “Powering Up the SG-1,” you can begin to install cards in the
SG-1 chassis.
Refer to guidelines for “Site Preparations” on page 1-2 to select the appropriate slot for a card, or refer to the
applicable card installation manual to select the appropriate slot and for detailed information on the card.
Step Action
1 Plug the RJ-45 connector of the Ethernet cable into the FAST E-NET port on the SG-1 chassis
back panel.
2 Connect the other end of the cable into the Ethernet port on the PC, hub, or other Ethernet device.
!
IMPORTANT Electrical and mechanical shock hazards are present throughout the system; be aware of this
possibility when power is applied to the chassis. Only qualified personnel should service the
system.
Step Action
1 Connect the power cord from the AC power connector on the SG-1 AC chassis back panel to the facility
power source. Turn on the power switch.
2 Verify that all cabling is securely terminated.
3 On each AC power supply, verify that the power LED lights green, indicating that the power supply is
receiving power.
Note: SG-1 cards are inserted under power (hot inserted).
CAUTION
When inserting the cards, make sure the cards are properly aligned on the tracks to prevent
equipment damage or personal injury.
