ADC SG-1 - Manual (Page 137)

June 30, 2006 Chapter 7: Second Level Commands
SG1-UM-8500-03 7-57
Example(s)
This command disables the system default routing process.
Usage
no router
Using the IP rip authentication key command
The ip rip command is located beneath the "configure terminal" menu. It is used to define the password for the
Router Information Protocol (RIP) authentication process.
Usage
ip rip authentication key
Parameter(s)
This is the authentication key.
Using the ip ospf interface command
This command defines an interface on which OSPF runs and defines the area ID for that interface.
Usage
ip ospf interface \
[\] area
Parameter(s)
The area ID for the interface on which OSPF is running.
For additional parameters, refer to “Using the ip igmp proxy command” on page 7-51 .
Host(config)# router id 10.33.21.88
Host(config)# no router
Host(config)# ip rip authentication key
Host(config)# ip ospf interface ... area
