ADC SG-1 - Manual (Page 101)

June 30, 2006 Chapter 7: Second Level Commands
SG1-UM-8500-03 7-21
[OAM]
Operation And Management mode
• on - Enable OAM mode
• off - Disable OAM mode
• on-cc - Enable OAM mode with continuity check
Example(s)
Configuring a range of PVC’s
Use this command to configure a range of PVC's on an ATM interface.
Usage
atm pvc range [name [pvc
name>] | [ OAM | ubr ]
Parameter(s)
The virtual path identifier (valid values 0 - 255).
The virtual channel identifier (valid values 32 - 2032).
The virtual channel identifier (valid values 32 - 2032).
The value 2 is required to select the SONET/SDH interface.
The port on which the circuit is to be created (valid values 1-2).
A logical interface number that can be used to group circuits (valid values 1 - 2000).
[pvc name]
A 1 to 64 character alpha-numeric identifier that can be assigned to a circuit for tracking purposes.
Host(config)# atm pvc 0 \ 60 \ 2 \ 1 \ 1
Added item
Host(config)#
Host(config)# atm pvc range
