Clearing Failed Devices
You can easily identify a failed device in the Storage window, its icon will
appear with a red X covering it. To clear the failed device from the Storage
menu, select Device, then Clear Failure.
Using Configuration Files
You can use a configuration file to save a particular subsystem configuration
and to view or reconstruct it at a later time. You can revert to one of these
saved configurations at any time. Client reads the configuration file you
choose and sets up your subsystem accordingly. In order to save or restore a
configuration, you must have a serial connection to both controllers.
Saving Configuration Settings to a File
1. From the Storage menu select Controller, Configuration, then Save
(Figure 3– 36).
Figure 3-36. Configuration file submenu
2. When the Save Configuration dialog box displays (Figure 3– 37), specify
a file name in the text box, then click the Save button. The current
configuration settings, including caches, LUNS, host port, and strip size
will be saved to a file at the location you specify.
Figure 3-37. Save Configuration dialog box
