Four target ports (WWPNs) on the source array are zoned in with two VPGs (VPG1 and
VPG2) on the MPX200.
•
LUNs associated with VPG1 are for Server1, and LUNs associated with VPG2 are for Server2.
•
Four global presented target ports (GPT1, GPT2, GPT3, and GPT4) depict the four source
array target ports discovered either on VPG1 and VPG2.
These presented targets (WWPNs) are zoned in with appropriate adapter ports on Server1,
and the same presented targets (WWPNs) are zoned in with the appropriate adapter ports
on Server2, creating a total of four presented targets through the MPX200.
•
Global Presentation 1 (SA1) and Global Presentation 2 (SA2) are presented through FC ports
on Blade1, and Global Presentation 3 (SB1) and Global Presentation 4 (SB2) are presented
through Blade2.
NOTE:
Do not use global presentation and LUN masking together. To use global presentation,
issue the lunremap command to mask LUNs. To use the lunmask add command, use VPG-specific
presentation rather than global presentation.
Example:
•
Four target ports on the source array are zoned in with all VPGs from each MPX blade.
Assuming two fabrics, connecting FC1 from each blade to Fabric A and FC2 from each blade
to FC2.
Source Array port WWPN
VPG WWPN
Zone
Fabric
50:05:08:b4:00:b4:78:cc
21:00:00:c0:dd:13:2c:60
21:01:00:c0:dd:13:2c:60
Blade1-FC1-VPG_Zone
A
21:02:00:c0:dd:13:2c:60
21:03:00:c0:dd:13:2c:60
50:05:08:b4:00:b4:78:c8
21:00:00:c0:dd:13:2c:68
21:01:00:c0:dd:13:2c:68
Blade2-FC1-VPG_Zone
A
21:02:00:c0:dd:13:2c:68
21:03:00:c0:dd:13:2c:68
50:05:08:b4:00:b4:78:cd
21:00:00:c0:dd:13:2c:61
21:01:00:c0:dd:13:2c:61
Blade1-FC2-VPG_Zone
B
21:02:00:c0:dd:13:2c:61
21:03:00:c0:dd:13:2c:61
50:05:08:b4:00:b4:78:c9
21:00:00:c0:dd:13:2c:69
21:01:00:c0:dd:13:2c:69
Blade2-FC2-VPG_Zone
B
21:02:00:c0:dd:13:2c:69
21:03:00:c0:dd:13:2c:69
•
Using Global mapping within the MPX200 Target Map feature, new Presented Target WWPN’s
are created for all VPGs for each source array port.
Source Array port WWPN
VPG
Presented Target WWPN
Presented out port
Fabric
50:05:08:b4:00:b4:78:cc
1,2,3,4
21:04:00:c0:dd:13:2c:60
Blade1-FC1 Blade2-FC1
A
50:05:08:b4:00:b4:78:c8
1,2,3,4
21:04:00:c0:dd:13:2c:68
Blade1-FC1 Blade2-FC1
A
50:05:08:b4:00:b4:78:cd
1,2,3,4
21:04:00:c0:dd:13:2c:61
Blade1-FC2 Blade2-FC2
B
50:05:08:b4:00:b4:78:c9
1,2,3,4
21:04:00:c0:dd:13:2c:69
Blade1-FC2 Blade2-FC2
B
