OPERATION
55
Select Thermocouple Type
The GDM-8342 accepts thermocouple inputs and calculates the
temperature from the voltage difference of two dissimilar metals.
Thermocouple type and reference junction temperature are also
considered.
Thermocouple
type and range Type Measurement Range Resolution
J -200 to +300˚C 0.1 °C
K -200 to +300˚C 0.1 °C
T -200 to +300˚C 0.1 °C
Procedure 1. Press the MENU key.
2. Go to TEMP on level 1.
3. Go to SENSOR on level 2.
4. Select the thermocouple type (J, K, T).
5. Press the Enter key to confirm.
6. Press the EXIT key to exit from the temperature
menu.
Display
Thermocouple
type setting
Sensor menu
indicator
