GETTING STARTED
17
Resistance/
Continuity)
/
W
dB
Measures resistance or continuity,
depending on the selected mode.
See page 43 and 48, respectively.
dB
(SHIFT→ Ω/ )
SHIFT
EXIT
→ /
W
dB Measures dB. See page 65.
Diode/
Capacitance
/
dBm Tests diodes or measures
capacitance, depending on the
selected mode. See page 45 and 46,
respectively.
dBm
(SHIFT →
/ ) SHIFT
EXIT
→ /
dBm Measures dBm. See page 63
Hz/P
Hz/P
TEMP
Measures the frequency or period
or a signal, depending on the
selected mode. See page 51.
TEMP
(SHIFT → Hz/P)
SHIFT
EXIT
→ Hz/P
TEMP Measures temperature. See
page 53.
2 ND
2ND
LOCAL
As the 2nd key, selects the
measurement item on the 2nd
display (page 57). Pressing and
holding for more than 1 second
turns off the 2nd display.
As the Local key, releases the
remote control and returns the
instrument to local panel
operation (page 105).
