GDM-834X Series User Manual
150
DC Voltage
Range Resolution Full Scale
Accuracy
(1 year 23˚C ±5˚C)
Input
Resistance
500mV 10 μ V 510.00
0.02%+4
10MΩ or
>10GΩ
5V 100 μ V 5.1000
10MΩ or
>10GΩ
50V 1mV 51.000 11.1MΩ
500V 10mV 510.00 10.1MΩ
1000V 100mV 1020.0 10MΩ
* When the input value exceeds the full scale of the selected range, the display will
show -OL- (over load) on the display.
* The specifications are guaranteed to an input voltage of 1000V. A beeping alarm
will go off when the input voltage is higher than 1000V.
* Input protection of 1000V peak on all ranges.
DC Current
Range Resolution Full Scale
Accuracy
(1 year 23˚C ±5˚C)
Shunt
Resistance
Burden
Voltage
500 μ A 10nA 510.00 0.05%+5 100Ω 0.06V max
5mA 100nA 5.1000 0.05%+4 100Ω 0.6V max
50mA 1 μ A 51.000 0.05%+4 1Ω 0.14V max
500mA 10 μ A 510.00 0.10%+4 1Ω 1.4V max
5 A 100 μ A 5.1000 0.25%+5 10mΩ 0.5V max
10 A 1mA 12.000 0.25%+5 10mΩ 0.8V max
* 500
μ
A~500mA range has a 3.6V voltage limit protection and 0.5A fuse
protection. And 10A range has a 12A fuse protection.
* When the input value exceeds the full scale of the selected range, the display will
show -OL- (over load) on the display.
* The specifications are guaranteed to an input of 10A. A beeping alarm will go off
when the input value is higher than 10A.
