GDM-834X Series User Manual

122

CONFigure2:RANGe?

Returns the range of the current function on the second display.
Return parameter:
DCV: 0 .5(500mV), 5(5V), 50(50V), 500(500V), 1000(1000V)
ACV: 0.5(500mV), 5(5V), 50(50V), 500(500V), 750(750V)
ACI: 0.0005(500μA), 0.005 (5mA), 0.05(50mA), 0.5(500mA), 5(5A),
10(10A)
DCI: 0.0005(500μA), 0.005 (5mA), 0.05(50mA), 0.5(500mA), 5(5A),
10(10A)
RES: 50E+1(500Ω ) 50E+2(5kΩ ), 50E+3(50kΩ ), 50E+4 (500kΩ ),
50E+5(5MΩ ), 50E+6(50MΩ )

CONFigure2:AUTO

Sets Auto-Range on or off on the 2nd display.
Parameter: ON | OFF
Example: CONF2:AUTO ON

CONFigure2:AUTO?

Returns the Auto-Range status of the function on the 2nd
display.
Return Parameter: 0|1, 1=Auto range, 0=Manual range
